Parameter Item |
MSG4 |
Module composition |
|
Pixel configuration |
SMD 3 in 1 |
Pixel pitch(mm) |
4 |
Module Resolution(WxH) |
80x40 |
Module Size(WxH) |
320x160 |
Module Weight(Kg) |
0.55±0.05 |
Module Area(m2) |
0.03686 |
Pixel Density(Dot/m2) |
62.500 |
Brightness(nits) |
≥ 4500 |
Color Temperature(K) |
2500-10000 Adjustable |
Horizontal Viewing Angle(°) |
160 |
Vertical Viewing Aangle(°) |
140 |
Deviation of LED Luminance |
<3% |
Brightness Uniformity |
≥97% |
Contrast Ratio |
5000:1 |
Electrical Parameters |
|
Max Power Consumption(W/m2) |
≤ 700 |
Average Power Consnumption(W/m2) |
≤ 235 |
Power Supply(V) |
DC:4.5 |
Module Current(A) |
7.5 |
Processing performance |
|
Driving mode |
Constant Current 10S |
Frame Rate(Hz) |
50&60 |
Refresh Rate(Hz) |
3840&1920 Optional |
Using Parameters |
|
Life Typical Value(hrs) |
100,000 |
Operating Temperature(°C) |
-10--40 |
Storage Temperature(°C) |
-25--60 |
Operating Humidity(RH) |
10—80% No condensation |
Storage Humidity(RH) |
10—85% No condensation |
